Availability: | |
---|---|
Quantity: | |
Product Application
Biological research
Pharmaceutical production
Food testing
Other fields that require precise temperature control for drying, curing, and incubation processes.
Product Feature
Stainless Steel Inner Chamber:
Made of mirror stainless steel with rounded corners for easy cleaning.
Adjustable shelves allow for flexible storage and improved space utilization.
Smart Temperature Control:
Microcomputer-based controller with high precision for reliable temperature control.
Features protection against overheating, sensor failure, current overload, and electrical leakage.
Visual and audible alarms for safety, along with a timing function for precise control.
Forced Air Circulation:
Forced hot air circulation ensures even temperature distribution throughout the chamber, providing consistent results.
Observation Window:
Double-layer glass observation window with silicon rubber seals for better sealing and easier observation of chamber contents.
Optional RS-485 Connectivity:
RS-485 port available for connection to an embedded printer to record and monitor temperature variations.
Parameter
Model | BOV-D35S | BOV-D60S | BOV-D70S | BOV-D140S | BOV-D240S |
Capacity | 35L | 60L | 70L | 140L | 240L |
Temp. Range | Incubator: RT+5~60℃; Oven: 80~250℃ | ||||
Temp. Resolution | 0.1℃ | ||||
Temp. Fluctuation | Incubator: ±0.5℃; Oven: ±1℃ | ||||
Timing Range | 1-9999min | ||||
Shelves No. | 2 | ||||
Ambient Temp | +5~35℃ | ||||
Power Supply | AC220±22V 50/60Hz (Standard); 110V 60/Hz (Optional) | ||||
Consumption | 500W | 700W | 1000W | 1500W | 2000W |
Internal Size(W*D*H) mm | 350*320*300 | 420*350*400 | 450*400*400 | 550*450*550 | 650*550*750 |
External Size(W*D*H) mm | 630*530*470 | 710*570*580 | 740*620*580 | 840*670*730 | 880*770*930 |
Package Size (W*D*H) mm | 730*630*570 | 810*670*680 | 840*720*680 | 940*770*830 | 980*870*1030 |
Gross Weight | 36kg | 43kg | 61kg | 88kg | 110kg |
Product Application
Biological research
Pharmaceutical production
Food testing
Other fields that require precise temperature control for drying, curing, and incubation processes.
Product Feature
Stainless Steel Inner Chamber:
Made of mirror stainless steel with rounded corners for easy cleaning.
Adjustable shelves allow for flexible storage and improved space utilization.
Smart Temperature Control:
Microcomputer-based controller with high precision for reliable temperature control.
Features protection against overheating, sensor failure, current overload, and electrical leakage.
Visual and audible alarms for safety, along with a timing function for precise control.
Forced Air Circulation:
Forced hot air circulation ensures even temperature distribution throughout the chamber, providing consistent results.
Observation Window:
Double-layer glass observation window with silicon rubber seals for better sealing and easier observation of chamber contents.
Optional RS-485 Connectivity:
RS-485 port available for connection to an embedded printer to record and monitor temperature variations.
Parameter
Model | BOV-D35S | BOV-D60S | BOV-D70S | BOV-D140S | BOV-D240S |
Capacity | 35L | 60L | 70L | 140L | 240L |
Temp. Range | Incubator: RT+5~60℃; Oven: 80~250℃ | ||||
Temp. Resolution | 0.1℃ | ||||
Temp. Fluctuation | Incubator: ±0.5℃; Oven: ±1℃ | ||||
Timing Range | 1-9999min | ||||
Shelves No. | 2 | ||||
Ambient Temp | +5~35℃ | ||||
Power Supply | AC220±22V 50/60Hz (Standard); 110V 60/Hz (Optional) | ||||
Consumption | 500W | 700W | 1000W | 1500W | 2000W |
Internal Size(W*D*H) mm | 350*320*300 | 420*350*400 | 450*400*400 | 550*450*550 | 650*550*750 |
External Size(W*D*H) mm | 630*530*470 | 710*570*580 | 740*620*580 | 840*670*730 | 880*770*930 |
Package Size (W*D*H) mm | 730*630*570 | 810*670*680 | 840*720*680 | 940*770*830 | 980*870*1030 |
Gross Weight | 36kg | 43kg | 61kg | 88kg | 110kg |
