| ltem No | SH7006 | SH9006 | SH9009 |
| Ice condenser capacity | 6kg | 6kg | 9kg |
| Ice condenser temperature | -70℃ | -90℃ | -90℃ |
| Chamber volume | 12L | 15L |
| Freeze dried chamber | Square cavity/front door opening/door opening angle up to 180 degrees |
| Sample shelf | ·Stainless steel template partition |
| ● Electric heating/optional |
| Vacuum pump | Extreme vacuum5*10mbar ,with a pumping capacity of 8m³/h |
| built-in to the host/optional for various types of pumps |
| Oil mist filter | Standard configuration |
| Vacuum pump connection pipe | Cold trap,condensing coil/all equipped with PTFE anti-corrosion treatment as standard. Freeze-drying organic solvents |
| Anti-corrosive treatment | Single forming stainless steel flexible pipe DN16 ISO-KF L-1.2m |
| Fxternal valve | 12 ports/optional | 1-48 ports/optiona |
| Eutectic point detection system | Support/Optional |
| Data export analysis | Support/Optional |
| Power | 0.95kw | 1.65kw |
| Size | 700*580*1600mm |
