Features:
Conductivity of 2nd stage RO water: 1-5µs/cm.
Resistivity of deionized water: more than 10MΩ.cm, near to18.2MΩ.cm.
Producing double-stage RO water and deionized water: you can get RO water and deionized water in a device, which can save your cost and improve efficiency.
Multiple alarm function: no feed water, full water, water quality's standard exceeding and cartidge replacing alarm.
Auto self-flushing of RO membrane: this kind of RO membrane has longer use life, which can can reduce maintenance costs.
High-capacity and easy-to-replacing cartridge: with fast inserted adapters, the cartridge is easy to replace and achieve running in the lowest cost.
Stainless steel shell: this water system is made of stainless steel with powder painting technics, achieving elegant appeaance and meeting GLP standard.
Floor type with wheels on the bottom design: this design makes it easy to move the water system.
Micro-computer control system with LCD display: LCD (resolution: 240×128, dimension: 106×57mm), intuitively display the system running state and various real-time parameters.
Comprehensive monitoring system: 3-way online water quality sensors detect the quality of feed water, RO water and ultrapure water.
Flow Schematic
Specifications
Model | Medium-RQ30 | Medium-RQ45 | Medium-RQ60 | Medium-RQ90 |
Output -1st stage RO water* | 63 liters/hour | 93 liters/hour | 125 liters/hour | 150 liters/hour |
Output -2nd stage RO water* | 30 liters/hour | 45 liters/hour | 60 liters/hour | 90 liters/hour |
Output -deionized water* | <30 liters/hour | <45 liters/hour | <60 liters/hour | <90 liters/hour |
Pure water outlet | 3: 1st and 2nd stage reverse osmosis water, deionized water | |||
Deionized water quality | ||||
Resistivity | 10-18.2MΩ.cm | |||
Bacteria | <0.01cfu/ml | |||
Particle(>0.2µm) | <1/ml | |||
RO water quality | ||||
Conductivity - 1st stage RO water | Feed water conductivity×5%* | |||
Conductivity - 2nd stage RO water | 1-5µs/cm* | |||
Feed water requirements | Tap water, temperature:5-45°C,pressure:1.0-4.0Kgf/cm2 | |||
Dimension and weight | Length×Width×Height:640×540×1110mm / Weight: about 75Kg | |||
Electrical requirements | AC110-240V, 50/60Hz | |||
Power | 240W | 240W | 240W | 360W |
Standard configuration | Main body (Including 1 set of cartridge)+built-in 15 liters pressure tank and buffer tank |
Cartridges
Item no. | Commodity | Approximate replacement term /set | |
PC-20PP | 20" spun fiber cartridge | 2-6 months | |
PC-20AC-G | 20" granular active carbon cartridge | 2-6 months | |
PC-20AC-B | 20" active carbon block cartridge | 2-6 months | |
RO-150GPD | 150 GPD reverse osmosis membrane | 12-24 months | |
RO-200GPD | 200 GPD reverse osmosis membrane | 12-24 months | |
RO-300GPD | 300 GPD reverse osmosis membrane | 12-24 months | |
RO-400GPD | 400 GPD reverse osmosis membrane | 12-24 months | |
RO-600GPD | 600 GPD reverse osmosis membrane | 12-24 months | |
PTC-AC-HZB1 | Reducing TOC cartridge | 9000 liters pure water | |
PTC-MBR-12L | 12l mixed bed resin cartridge | 20000 liters pure water | |
PTC-UPPR-12L | 12l ultrapure polishing resin cartridge | 20000 liters pure water | |
PTC-MBR-25L | 25l mixed bed resin cartridge | 40000 liters pure water | |
PTC-UPPR-25L | 25l ultrapure polishing resin cartridge | 40000 liters pure water | |
PTC-UPPR-M | Ultrapure polishing resin cartridge | 1000 liters pure water/set | |
TF-0.2µm-B | 0.2µm terminal filter | - | |
UF-5000D | MWCO5000D UF cartridge | - | |
LAMP-(185nm&254nm)-10W-M | Double wavelength(185&254)nm uv lamp | 9000 hours |
