Features:
6-Position Cell Holder: the spectrophotometer includes an automatic 6-position cell holder, suitable for optical path lengths between 10 and 50mm, allowing flexible and accurate sample measurement.
Reinforced Base and Stability: with a thickened and reinforced base, the instrument ensures stability, improving the accuracy of the optical path and overall measurement reliability.
Sealed Optical Path Design: a sealed design helps protect the optical path from external influences, enhancing measurement consistency and extending the instrument’s service life.
Long-Life Lamps and Easy Replacement: equipped with Deuterium and Tungsten lamps with a minimum lifespan of 2000 hours, the instrument’s socket design allows for easy lamp replacement, ensuring longevity.
Precision Gratings and Optical Mirrors: the instrument uses 1200 line/mm holographic gratings and moisture-proof coated optical mirrors, optimizing both the accuracy of measurements and the instrument's overall durability.
Connectivity and Data Output: it offers USB and Bluetooth data output for seamless connectivity with external devices, as well as printing capabilities for easy result documentation.
Versatile Measurement Functions: supporting a wide range of testing modes, including photometric, quantitative, kinetic, and multi-wavelength functions, the instrument is versatile for various analytical needs.
GMP-Compliant Software (Optional): the optional PC software meets GMP requirements and features multi-user management and audit tracking, ensuring compliance and secure data management.
Parameters
Model |
BK-UV6T |
Optical System |
1200 line/mm Grating, Single Beam |
Wavelength Range |
190~1100mm |
Spectral Bandwidth |
2.0nm |
Wavelength Accuracy |
±0.5nm(@D656.1±0.1nm) |
Wavelength Repeatability |
≤0.2nm |
Photometric Accuracy |
±0.002A(0-0.5Abs), ±0.004A(0.5-1.0Abs), ±0.2% T(0-100% T) |
Photometric Repeatability |
±0.001A(0-0.5Abs), ±0.002A(0.5-1.0Abs), ±0.1%T(0-100%T) |
Stray Light |
≤0.04T@360nm; 220nm |
Stability |
±0.001A/h@500nm |
Baseline Flatness |
±0.001A |
Noise |
±0.001Abs |
Display |
1024*600 7 inch touch screen |
Photometric Mode |
T, A, C, E |
Photometric Range |
0-200%T,-4.0-4.0A,0-9999.9C |
Detector |
Silicon Photodiode |
Light Source |
Deuterium Lamp, Tungsten Lamp |
Input |
Touch Screen |
Interface |
USB-A*2, USB-B*1, Blue Tooth |
